Magnesium Chloride MGO Board
Home - Products - Magnesium Chloride MGO Board
Fireproof Decorative Building Interior Wall MgO Board
Fireproof Decorative Building Interior Wall MgO Board
Fireproof Decorative Building Interior Wall MgO Board
Fireproof Decorative Building Interior Wall MgO Board
Fireproof Decorative Building Interior Wall MgO Board

Fireproof Decorative Building Interior Wall MgO Board

Can be made into various sizes as needed
Fireproof decorative building interior wall substrates like mgo board
class A1 fire proof
various sizes and colors(grey ,white,red,etc) according to needs
Produt Details





Fireproof decorative building interior wall mgo board



The material components for producing glass magnesium fireproof board are active high-purity magnesium oxide (MgO), high-quality magnesium chloride (MgCl2), magnesium sulfate (MgSO4), alkali-resistant glass fiber cloth, plant fiber, non-combustible light perlite, chemically stable lithopone, high Molecular polymers, performance improvements, and more.

Fireproof Interior Wall Panels|Wall Panels| Interior Wall MGO Board|MgO Boards

Magnesium Oxide Board



Data Sheet



Describtion Result  Test Standatd
Bending strength(Dry conditions) 14.27N/mm² ASTMC1185 Section 5
Bending strength(Wet conditions)  13.0N/mm²  ASTMC1185 Section 5
Mositure content(Degree90±2℃) 2.5% ASTMC1185 Section 10
Water absorption(48 hours at room temperature )   30.17%   ASTMC1185   Section   9
Moisture resistance (average mm) Nil ASTM C473:2017,Clause 14
Flexural strength(12mm thickness)  ≥1100N/mm²  ASTM C1185 Section 8
Flexural strength(12mm thickness)           ≥1100N/mm² ASTM C1185 Section 8
Flexural strength(9mm thickness) ≥800N/mm2 ASTMC1185 Section 8
Flame spread index (FSI)   0(CLASS A) ASTM E84-18
Chloride Ion Measurement   0.085% ASTM C871-11









Product Detail Presentation



We can make mgo boards of various sizes according to needs. Insulation panels are widely used in construction and industrial fields to improve the thermal performance of buildings and equipment, reduce energy consumption and improve indoor environment.

The following are common application areas for our boards:



  1. Exterior wall insulation: Install insulation panels on the exterior walls of buildings to reduce indoor heat loss, improve the overall thermal performance of the building, and achieve energy saving effects.
  2. Roof insulation: Install insulation panels below or above the roof structure of the building to reduce the loss of heat from the roof and improve the insulation performance of the roof.
  3. Floor insulation: used to install under the floor of a building to prevent ground heat from escaping downward and improve the warmth of the indoor floor.
  4. Indoor insulation: Use insulation panels inside walls or partitions to improve indoor insulation and reduce conducted heat.
  5. Pipe and equipment insulation: Used to cover pipes and equipment to reduce energy loss and maintain the temperature of fluids in pipes. It is suitable for industrial and HVAC systems.
  6. Cold storage and cold storage: Use insulation panels in the walls, roofs and floors of cold storage and cold storage to prevent the loss of cold energy and maintain a low temperature environment.
  7. Basement Insulation: Use insulation panels in a building's basement walls and floors to prevent basement leaks and increase indoor comfort.
  8. Industrial Facilities: Used on the walls, roofs and floors of industrial buildings to improve the energy-saving performance of industrial facilities.
  9. Agricultural buildings: In agricultural buildings, such as greenhouses, livestock houses, etc., used for insulation and energy saving.
  10. Vehicles: Used for heat insulation, sound insulation and thermal insulation of ships, airplanes, cars and other vehicles to improve comfort and energy-saving performance.
  11. Decorative materials: Some insulation boards also have decorative functions and can be directly used for wall or ceiling decoration.
  12. The performance characteristics of insulation boards: high fire resistance, high thermal insulation, relatively good strength, not easy to break, light weight, non-toxic and harmless, long life, good water resistance, good interface, energy saving and safety, etc.









Product Detail Presentation



Excellent fire protection

Beiyuan magnesium oxide has good fire resistance and is a non-combustible board, reaching the highest fire-proof and non-combustible grade A1.

Pest and mold resistance

BeiYuan MgO board anti-mold,anti-bacteria,anti-insect and anti-termite function,meet the European and American etc building materials anti-mold standard.

Sound Insulation

Excellent sound insulation performance ensures a quiet and elegant environment. The sound insulation of 6mm thick plate is 29dB, which is greater than 42dB.

Superior bending strength

It has a dense structure, good stability, no deformation, and has wood-like toughness. It has excellent impact resistance, compression resistance, tensile resistance, and fracture resistance. It is rigid and tough.

Waterproof and moisture-proof

The performance is stable and not affected by condensation of water droplets and humid air. Even if it is soaked in water for several days and taken out to dry naturally, it will not deform or soften.

Light weight

The apparent density of Beiyuan magnesium oxide is 0.8-1.2g/cm3, and its light weight is beneficial to the structure's earthquake resistance, effectively reducing the cost of the foundation and main structure.

High durability

The scientific formula completely solves the problems of moisture absorption and halogenation of glass magnesium fireproof board. After ten years of testing, the magnesium glass fireproof board is strong and durable, resistant to aging and has a long life.

Environmentally friendly and healthy

It does not contain asbestos, formaldehyde, benzene and harmful radioactive elements. It is smoke-free, non-toxic and has no odor when exposed to fire. Natural mineral powder and plant fiber raw materials, energy saving and environmental protection.

Heat insulation and energy saving

The inorganic material has good properties, with a thermal conductivity of 0.216w/cm-k, which is more insulating than the 1.1w/cm-k of Ai sand blocks, saving energy consumption and keeping the room comfortable and beautiful.

Multifunctional product

Unique smooth and rough surfaces provide functional versatility for customer use. The smooth surface can be pasted with wallpaper, spray paint or latex paint, etc.; the rough surface can be pasted with ceramic tiles, dust and latex paint.

High quality and competitive price

Over 20 years of experience oem factory,factory price guarantee quality,cost-effectiveproducts on the market!







Application Case Scenarios





composition for the production of active high-puritymagnesium oxide (MgO), high-quality magnesiumchloride (MgC12), magnesium sulfate (MgSO4), alkalifiberglass cloth, plant fibers, non-combustible lightweight perlite, chemically stabilized Lidl powder, polymers, high-performance modifiers, and so on.









Our Factories and Warehouses



Qingdao Beiyuan Environmental Protection Building Materials Co., Ltd. is located at No. 20, Shandong Road, Beiguan Industrial Park, Jiaozhou City, Qingdao, Shandong Province. It covers an area of 38 acres, has a factory area of 14,000 square meters, and has complete office buildings, canteens, and dormitories.



The company produces and operates green environmentally friendly building materials, glass magnesium fireproof board substrates, with a daily production capacity of more than 2,500 substrates, a daily output of 7,500 square meters, and an annual production capacity of approximately 2,310,000 square meters.
